Volvo EC27D
Compact excavators
- Extended warranty
- Flexible financing
- Tailored service contracts
Do more, everywhere with the Volvo EC27D compact excavator. Delivering best-in-class performance, it offers impressive lifting capacity and strong digging force to handle a wide range of tasks. Built for durability, versatility, and ease of operation, it’s designed to help you work efficiently across every job.
A powerful 2.7-ton performer, the EC27D delivers excellent digging force and lifting capacity, enabling you to stretch further, dig deeper, and reach higher with a single compact machine. Designed for ease of operation and simplified servicing, it helps maximize uptime and profitability. Versatile and reliable, the EC27D is a high-performing partner for landscaping, utility work, and construction applications.
Technical specifications
Here are the key specifications for EC27D. Want more details? Download the brochure or contact us.
- Min. Operating weight 6 019 - 6 019 lb
- Min. Excavator bucket capacity 0.09 yd³
- Gross power (kW) 20.90 hp
- Gross power (HP) 20.90 hp
- Engine D1.1A
- Max. flow hydraulic pump 17.20 gal/min
- Max. slew speed 9.40 rpm
- Max. slew torque 3 540 lbf·ft
- Max. drawbar pull 5 620 lbf
- Max. breakout force 5 528 lbf
- Max. tear out force 4 060 lbf
- Max. digging reach 15.31 ft
- Max. digging depth 10.14 ft
- Max. cutting height 15.09 ft
- Tail swing radius 3.55 ft
- Sound level in cab (LpA) 78 dB
- External sound level (LwH) 93 dB
Benefits & Features
Here are the key benefits and features of the EC27D. Want to know more? Download the brochure or get in touch with us.
Best-in-Class Performance
Experience the power to do more. With excellent digging forces and impressive lifting capacity, the EC27D can handle tough jobs with ease, delivering the performance you need to maximize your productivity.
Ease of Operation and Control
The spacious cab and intuitive fingerprint controls ensure smooth, simultaneous movements. This user-friendly design allows operators of all skill levels to work with precision and confidence from day one.
Optimized Serviceability for Maximum Uptime
Designed with easy access to all key service points, the Volvo EC27D minimizes downtime and maintenance hassle. Quick-check panels and grouped components simplify daily inspections and routine servicing, helping you keep the machine running smoothly and efficiently, so you can focus on the job without interruptions.
