Volvo EC750E
Large crawler excavators
- Extended warranty
- Flexible financing
- Tailored service contracts
Increase productivity and maximize return on investment with the Volvo EC750E. This 75-ton crawler excavator combines exceptional power and stability for high-capacity applications. Powered by Volvo’s Tier 4 Final D16 engine, it delivers responsive performance, strong digging force, and reliable results in demanding environments.
Built on decades of Volvo engineering expertise, the EC750E integrates advanced technology to enhance hydraulic efficiency, shorten cycle times, and reduce operating costs. Its reinforced structure and durable components make it ideal for large-scale earthmoving, quarrying, and heavy construction.
Stronger, faster, and more efficient than ever, the EC750E is designed to handle the biggest jobs with ease while delivering long-term productivity and profitability.
Technical specifications
Here are the key specifications for EC750E. Want more details? Download the brochure or contact us.
- Min. Operating weight 161 158 - 165 150 lb
- Min. Excavator bucket capacity 4.32 - 7.98 yd³
- Gross power (kW) 526 hp
- Gross power (HP) 526 hp
- Engine D16J
- Max. flow hydraulic pump 237.80 gal/min
- Max. slew speed 7 rpm
- Max. slew torque 203 198 lbf·ft
- Max. drawbar pull 106 110 lbf
- Max. breakout force 80 710 lbf
- Max. tear out force 67 000 lbf
- Max. digging reach 45.17 ft
- Max. digging depth 29.67 ft
- Max. cutting height 42.42 ft
- Tail swing radius 13.58 ft
- Sound level in cab (LpA) 72 dB
- External sound level (LwH) 108 dB
Benefits & Features
Here are the key benefits and features of the EC750E. Want to know more? Download the brochure or get in touch with us.
Powerful and Efficient Volvo Engine
At the heart of the machine is the powerful Volvo D16 engine. It delivers high torque at low rpm, providing the perfect combination of immense power and impressive fuel efficiency, which results in lower operating costs and higher profitability.
Reinforced for Heavy-Duty Applications
Engineered for maximum uptime in the toughest jobs like quarrying and mass excavation. The reinforced boom, arm, and robust undercarriage ensure the EC750E can withstand high-impact forces, delivering ultimate durability and reliability.
Advanced Electro-Hydraulic System
Experience fast cycle times and superior control with the advanced electro-hydraulic system. It is optimized to work in harmony with the engine, providing high hydraulic flow for smooth, responsive, and highly productive combined operations.
