Volvo ECR88D
Compact excavators
- Extended warranty
- Flexible financing
- Tailored service contracts
The Volvo ECR88D compact excavator provides safe access to more job sites. Its short swing radius design allows confident operation closer to obstacles in road construction, utilities, and landscaping, while a heavy counterweight and strong undercarriage deliver outstanding stability.
As a powerful 8-ton performer, the ECR88D combines agile design with a heavy counterweight and robust undercarriage to deliver superior stability and strong lifting capacity, handling demanding tasks with confidence.
From a comfortable, well-designed cab with excellent visibility, operators can work productively and safely. Versatile and reliable, the ECR88D is engineered to enhance performance and profitability in space-restricted applications.
Technical specifications
Here are the key specifications for ECR88D. Want more details? Download the brochure or contact us.
- Min. Operating weight 19 295 - 19 758 lb
- Min. Excavator bucket capacity 0.10 - 0.43 yd³
- Gross power (kW) 55 hp
- Gross power (HP) 55 hp
- Engine D2.6H
- Max. flow hydraulic pump 50 gal/min
- Max. slew speed 8.30 rpm
- Max. slew torque 16 890 lbf·ft
- Max. drawbar pull 14 613 lbf
- Max. breakout force 12 860 lbf
- Max. tear out force 8 950 lbf
- Max. digging reach 24.12 ft
- Max. digging depth 14.87 ft
- Max. cutting height 23.13 ft
- Tail swing radius 4.24 ft
- Sound level in cab (LpA) 74 dB
- External sound level (LwH) 98 dB
Benefits & Features
Here are the key benefits and features of the ECR88D. Want to know more? Download the brochure or get in touch with us.
Short Swing, High Stability
Work safely in tight spaces. The short swing radius lets you work close to obstacles, while the robust undercarriage and counterweight provide the stability and lifting power of a larger conventional machine.
Superior Visibility and Comfort
The spacious Volvo cab is designed for operator productivity. With large glass areas for all-around visibility and ergonomic controls, it creates a safe and comfortable workspace that reduces fatigue.
Easy Service and Maintenance
Maximize your uptime with easy, ground-level access to grouped daily service points. This smart and simple design makes routine checks faster and safer, ensuring your machine is always ready to work.
