Bobcat PG25
Bobcat Generators
- Extended warranty
- Flexible financing
- Tailored service contracts
The Bobcat® PG25 delivers 25 kVA (20 kW) of quiet, reliable power in a compact design. With intuitive gauges, a user-friendly control panel, and 25‑hour runtime, it’s ready to keep events, job sites, or emergency backup running smoothly.
The Bobcat® PG25 portable generator offers 25 kVA (20 kW) of dependable power in a rugged, compact frame. Analog gauges provide clear performance monitoring, and the user-friendly control panel simplifies operation. With a 25‑hour maximum runtime at full load, it’s ideal for construction sites, events, or emergency power, delivering quiet, continuous performance with minimal supervision.
Technical specifications
Here are the key specifications for PG25. Want more details? Download the brochure or contact us.
- Prime Power 25 kVA/kW
- Standby Power 27.50 kVA/kW
- Power Factor 0.80
- Frequency 60 Hz
- Voltage 120 V
- Sound Level 62 dB(A)
- Emissions Tier Level Tier 4 Final
- Engine Make Bobcat
- Number of Cylinders 3
- Displacement 110 in³
- Bhp @ Rated Speed 33 hp
- Rated Speed 1 800 rpm
- Fuel Tank Capacity 47 gal
- Runtime Hours 30 h
- Operating Weight 2 800 lb
- Length 130.50 ft
- Width 68.30 ft
- Height / Clearance 6.38 ft
- Intelligent Load Management System (ILMS) Yes
- Drive variants Combustion
Benefits & Features
Here are the key benefits and features of the PG25. Want to know more? Download the brochure or get in touch with us.
Extended Runtime for Continuous Jobsite Power
The Bobcat PG25 portable generator offers an impressive 30 hours of runtime at 75% load, supported by a large 47-gallon fuel tank. This extended runtime minimizes refueling interruptions, enhancing productivity and ensuring reliable power throughout extended work shifts on the jobsite.
Versatile Voltage Output for Diverse Equipment Needs
With a 3-position voltage switch and multiple output options including 480V, 240V, 208V, and 120V in both single and three-phase configurations, the PG25 adapts easily to varied jobsite power requirements. This flexibility supports a wide range of tools and machinery, improving operational efficiency.
Quiet Operation to Reduce Jobsite Noise Disruption
Operating at a sound level of just 62 dB(A), the PG25 portable generator delivers powerful 25 kVA output with minimal noise. This quiet performance helps maintain a safer and more comfortable work environment, allowing crews to focus on tasks without excessive noise distractions.
