Volvo EC250E
Large crawler excavators
- Predictable costs and total control
- Modern equipment with cutting-edge technology
- Rent only for the time you need
Move more for less with the upgraded Volvo EC250E. Combining proven technology with a new Volvo engine, advanced hydraulics, and optional Dig Assist apps, it helps lower cost per tonne while delivering the reliability, performance, and operator environment expected from Volvo.
With improved access, outstanding visibility, extended service intervals, and the support of Volvo Attachments and Volvo Services, the EC250E delivers the reliability, performance, and operator comfort that define Volvo. Built for durability and productivity, it is a dependable partner for demanding construction projects.
Technical specifications
Here are the key specifications for Volvo EC250E. Want more details? Download the brochure or contact us.
- Min. Operating weight 59 150 - 60 460 lb
- Min. Excavator bucket capacity 0.73 - 2.35 yd³
- Gross power (kW) 224 hp
- Gross power (HP) 224 hp
- Engine D8M
- Max. flow hydraulic pump 126.80 gal/min
- Max. slew speed 11.70 rpm
- Max. slew torque 67 634 lbf·ft
- Max. drawbar pull 48 784 lbf
- Max. breakout force 40 710 lbf
- Max. tear out force 28 740 lbf
- Max. digging reach 32.58 ft
- Max. digging depth 22.08 ft
- Max. cutting height 31.50 ft
- Tail swing radius 9.42 ft
- Sound level in cab (LpA) 70 dB
- External sound level (LwH) 104 dB
Benefits & Features
Here are the key benefits and features of the Volvo EC250E. Want to know more? Download the brochure or get in touch with us.
Powerful Volvo D8 Engine
The renowned Volvo D8 engine provides high torque at low rpm for the ultimate combination of performance and fuel efficiency. This powerful heart ensures the machine has the power to tackle the toughest jobs.
Advanced Electro-Hydraulic System
Increase your productivity with a harmonized hydraulic system. It provides high responsiveness and control for smooth, fast cycle times. Operators can perform combined movements with precision for greater efficiency.
Reinforced for Heavy-Duty Work
Engineered to withstand the rigors of mass excavation and quarrying. With a robust boom, arm, and a durable undercarriage, the EC250E is built for maximum uptime and a long, productive service life.
