Volvo EC500 Straight Boom
Demolition equipment
- Predictable costs and total control
- Modern equipment with cutting-edge technology
- Rent only for the time you need
The Volvo EC500 Straight Boom is a specialized partner for versatile demolition tasks, built around three core principles: reach, stability, and protection. Based on the powerful 50-ton platform, it delivers extended reach, machine protection, and purpose-built demolition features to maximize productivity in the toughest applications.
Offering significantly greater forward reach than a standard excavator, the EC500 Straight Boom is ideal for demolishing structures from a safe distance, sorting rubble, and working below ground level. Enhanced stability and a strong design provide a solid platform for handling heavy demolition tools with precision and control.
With all-around machine protection and a strong focus on operator safety, the EC500 Straight Boom is built for durability, uptime, and productive demolition performance.
Technical specifications
Here are the key specifications for Volvo EC500 Straight Boom. Want more details? Download the brochure or contact us.
- Min. Operating weight 135 143 - 135 143 lb
- Max. allowable tool weight 16 lb
- Gross power (kW) 417 hp
- Gross power (HP) 424 hp
- Engine D13J
- Max. flow hydraulic pump 99.30 gal/min
- Max. slew speed 9.30 rpm
- Max. slew torque 122 435 lbf·ft
- Max. drawbar pull 74 861 lbf
- Max. breakout force 69 016 lbf
- Max. tear out force 58 226 lbf
- Max. digging reach 35.92 ft
- Max. digging depth 21.58 ft
- Max. cutting height 20 ft
- Tail swing radius 12.75 ft
- Sound level in cab (LpA) 71 dB
- External sound level (LwH) 107 dB
Benefits & Features
Here are the key benefits and features of the Volvo EC500 Straight Boom. Want to know more? Download the brochure or get in touch with us.
Purpose-Built Straight Boom
Gain a significant advantage with the 14.5-meter straight boom, providing up to 30% more pin height than a standard machine. This design is perfect for extended forward reach, giving you the power to demolish and sort with superior range and efficiency.
Enhanced Protection Package
Work with confidence in the toughest demolition environments. The machine features extensive guarding, including a frame-mounted Falling Object Guard (FOG), reinforced side doors, and robust underbelly protection to maximize durability and safety.
Superior Stability
Handle heavy demolition tools with ease thanks to a heavier counterweight and robust undercarriage. This solid and well-balanced platform provides the stability needed to operate powerful attachments at an extended reach with precision and control.
