Volvo EC750E High Reach
Demolition equipment
- Predictable costs and total control
- Modern equipment with cutting-edge technology
- Rent only for the time you need
Built, engineered, and supported entirely by Volvo, the EC750E HR is purpose-designed for high-reach demolition. This 75-ton crawler excavator combines exceptional power and stability to handle high-capacity demolition with confidence. Powered by the Volvo Tier 4 Final D16 engine delivering 374 kW (502 hp), it provides highly responsive performance to maximize productivity and ensure a strong ROI.
Based on a powerful 75-ton platform, the EC750E HR delivers impressive high-reach capability with a pin reach of up to 36 meters. Designed for more than demolition, it can be quickly adapted for standard digging, making it a versatile and profitable asset for specialized fleets.
Built with safety at its core, the machine features a stable undercarriage and reinforced structure to protect operators while maintaining the performance and control contractors need for demanding demolition projects.
Technical specifications
Here are the key specifications for Volvo EC750E High Reach. Want more details? Download the brochure or contact us.
- Min. Operating weight 197 225 - 227 138 lb
- Max. allowable tool weight 8 lb
- Gross power (kW) 527 hp
- Gross power (HP) 534 hp
- Engine D16J
- Max. flow hydraulic pump 118.90 gal/min
- Max. slew speed 7 rpm
- Max. slew torque 203 051 lbf·ft
- Max. drawbar pull 106 110 lbf
- Max. breakout force 71 264 lbf
- Max. tear out force 59 799 lbf
- Max. digging reach 37.60 ft
- Max. digging depth 23.67 ft
- Max. cutting height 35.92 ft
- Tail swing radius 13.58 ft
- Max. pin height 46.50 ft
- Pin height H/2 41.23 ft
- Max. pin reach 26.64 ft
- Pin reach H/2 22.41 ft
- Sound level in cab (LpA) 72 dB
- External sound level (LwH) 108 dB
Benefits & Features
Here are the key benefits and features of the Volvo EC750E High Reach. Want to know more? Download the brochure or get in touch with us.
Exceptional High-Reach Boom
Demolish taller buildings safely and efficiently with the market-leading 36-meter high-reach boom. This impressive reach allows you to work at a safe distance from the structure, maximizing productivity and ensuring the highest level of safety.
Hydraulically Retractable Undercarriage
Benefit from superior stability during work and easier transportation between sites. The hydraulically retractable undercarriage provides a wide, stable footprint for high-reach tasks and can be narrowed to reduce its width for transport.
Multi-Use Demolition Solution
Increase your machine’s utilization with a versatile, multi-use design. The innovative hydraulic modular joint allows for a quick and easy switch between the high-reach boom and a standard digging boom, making it two machines in one.
